Technical Specifications
V4 Supercharger Post
Max Output Power
500 kW
Continuous Current
615 A
Voltage Range
0–500 VDC (V3 Cabinet)
0 - 1000 VDC (V4 Cabinet)
Cable Length
3 m
Communication
Supports open protocols, ISO15118-2, OCPI capable
Payment Terminal
Optional
Charging Standards
NACS, CCS1, CCS2, GB/T
V4 Supercharger Cabinet
Max DC Output
Up to 1200 kW, shared by 8 posts
Output Voltage Range (DC)
180–1000 VDC
Cabinet-to-Post Cable Distance
Up to 100 m
Efficiency
>96%
Cooling
High efficiency, low noise, ventilation not required
V3 Supercharger Cabinet
Max DC Output
Up to 387 kW, shared by 4 posts
Output Voltage Range (DC)
180 - 500 VDC
Cabinet-to-Post Cable Distance
Up to 75 m
Efficiency
96%
Cooling
High efficiency, low noise, ventilation not required
